ARK-DS520 Advanced (ION2 based) Graphics Digital Signage Platform
£0.00 excl. vat
Advanced (ION2 based) Graphics Digital Signage Platform
Out of stock
Please click the link below to open the PDF datasheet
View Datasheet - Integrated NVIDIA GT218 (ION2) graphic module for Full HD playback
- Rich video I/O combination supports dual display (eg: 2 x VGA, VGA + HDMI, HDMI + DVI, VGA+DVI)
- Embedded Intel® Atom™ D525 dual-core (fan) or Intel® Atom™ N455 single-core process (fanless)
- Compact, low-profile design for easy installation
- Highly expandable via internal Mini PCIe interface (eg: WLAN, 3G or TV tuner)
- RS-232 and DIO ports convenient for system integration and applications
- Consumer Electronic Control (CEC) implemented on HMDI (*1)
- Supports iManager, SUSIAccess and Embedded Software APIs
- CPU:
- System Chipset:
- L2 Cache: 1 MB/512 KB (Depends on CPU Type)
- BIOS: AMI 16 MB SPI BIOS
- Technology: 2 x DDR3 204-pin SO-DIMM 1 x DDR3 204-pin SO-DIMM
- Max. Capacity: Max. up to 4 GB (w/D525); or 2 GB (w/N455) Default 2 GB
- Chipset: NVIDIA GT218
- Memory Size: Independent display memory 512 MB
- Resolution (Chipset support):
- Output: HDMI x 1, DVI-D x 1, VGA x 2 HDMI x 1, VGA x 1
- Dual Display: Any 2 display outputs simultaneously
- Video Format: Blu-ray, MPEG2, MPEG4 Part 2 Advanced Simple Profile, H.264, VC1, DivX version 3.11 and later (*2)
- SATA: 2.5″ SATA HDD (7.0 mm height only)
- CF: CompactFlash socket for type I/II Default 16GB CF card (MLC)
- Interface: Gigabit LAN Controller
- Controller:
- Connector: 2 x RJ-45 1 x RJ45
- HDMI: 1 1
- DVI-D: 1 N/A
- VGA: 2 (D-sub 15-pin) 1
- LAN: 2 (RJ-45) 1 (LAN1)
- USB: 4 (USB 2.0 compliant) 4 (USB 2.0 compliant)
- Audio: 2 audio phone jacks for Line-out, Mic-in
- Serial: 2 x COM (RS-232) 1 (COM1)
- Digital: I/O 1 DB9 (Female type) N/A
- Mini-PCIe (Internal): 2 (for optional expansion modules) 1
- Power input 1 (DC-in Jack) 1 (DC-in Jack)
- Management: ACPI 2.0
- Power Consumption: Input Voltage Average 18W, Maximum 30W
- Input Voltage: 12 V DC-in (ATX/AT mode, default ATX)
- Other: Supports Boot on Power Back and Scheduled Boot Up functions
- Output: Interrupt, system reset
- Interval: 255-level timer interval, setup by software
- Mounting: Desktop/Wall Mount
- Dimensions (W x H x D): 220 x 44.2 x 150 mm
- Weight: 1.7 kg (3.74 lb)
- Temperature: 0 ~ 40° C (32 ~ 104° F), operating -20 ~ 70° C (-4 ~ 158° F), storage
- Relative Humidity: 95% @ 40° C (non-condensing), operating
- Vibration Resistance: 0.3 Gms, IEC 60068-2-64, Random 5-500Hz, 1hr/axis
- Operating System: Supports Microsoft Windows 7, XP with SP3, XP Embedded, Linux
- EWF & WDT SDK: EWF and WDT library for signage stability design in XPE
- Linux: Linux Fedora 14
- Electromagnetic: CE/FCC Class A, CCC, BSMI
- Safety: UL, CCC, BSMI
Processor System
Intel Atom D525 1.8 GHz, Intel Atom N455 1.66 GHz Intel Atom D525 1.8 GHz
Intel Atom D525/N455 + ICH8M
Intel Atom D525 + ICH8M
Memory
Display
VGA: up to 2048 x 1536 @ 60Hz
DVI-D: single link 1600 x 1200 @ 60Hz
HDMI: up to 1920 x 1080p
Storage
Ethernet
Intel 82567V for LAN 1
Realtek RTL8111E for LAN2 Intel 82567V
I/O Interface
(support Jack Sense) 1 (Line-out)
Power Requirement
Watchdog Timer
Physical Characteristics
Environment
0 ~ 50° C (32 ~ 122° F), operating -20 ~ 70° C (-4 ~ 158° F), storage
Software Development Kit
Certification
