ARK-3360L Intel® Atom™ N450/D510 High Value Fanless Embedded Box PC with Multiple I/O
Call for Price
Intel® Atom™ N450/D510 High Value Fanless Embedded Box PC with Multiple I/O
Please click the link below to open the PDF datasheet
View Datasheet - Intel® Atom™ N450/D510 1.66 GHz Fanless Embedded Box PC
- Supports extend temperature -40 ~ 70° C (ARK-3360LZ-N4A1E)
- Mini PCIe expansion for communication module, i.e. HSDPA, WLAN
- Dual display and supports for wide screen with high resolution
- Supports up to 2 x GbE, 6 x USB 2.0 and 4 x COMs ports
- Serial port RS-485 auto-flow support
- Easy integration, easy maintenance
- Supports SUSIAccess and Embedded Software APIs
- Supports SUSIAccess and Embedded Software APIs
- Processor System
- CPU: Intel Atom N450 Single Core
- Frequency: 1.66 GHz
- L2 Cache: 512 KB
- System Chipset: Intel ICH8-M
- BIOS: AMI 16 Mbit Flash BIOS
- CPU: Intel Atom D510 Dual Core
- Frequency: 1.66 GHz
- L2 Cache: 1 MB
- System Chipset: Intel ICH8-M
- BIOS: AMI 16 Mbit Flash BIOS
- Technology: DDR2 667 MHz
- Max. Capacity: 2 GB
- Socket: 1 x 200-pin SO-DIMM
- Chipset: Intel 3.5 Gen Integrated Graphic Engine
- Interface: VGA: N450 up to 1400 x 1050, D510 up to 2048 x 1536
- LAN 1: 10/100/1000 Mbps Intel 82567V GbE, support Wake On LAN
- LAN 2: 10/100/1000 Mbps Intel 82583V GbE, support Wake On LAN
- Amplifier: –
- Interface: Line-in, Line-out, Mic-in
- Serial Interface: 3 x RS-232 port, 1 x RS-232/422/485 port w/Auto flow control
- USB Interface: 6 x USB ports, Compliant with USB 2.0
- Digital I/O: 8-bits
- Watchdog timer: 255-level timer interval, setup by software
- Mini PCI: –
- Mini PCIe: 1 x full-size Mini PCIe
- HDD: Supports 1 x SATA 2.5″ HDD Bay (support 9.5 mm height only)
- SSD: Supports CompactFlash socket for type I/II CompactFlash disk
- Microsoft Windows: Windows 7, XP Professional, XP Embedded, WinCE 6.0
- Linux: Ubuntu 10.04, QNX 6.5, Vxwork 6.8
- Power Type: AT/ATX
- Power Input: Voltage 12 VDC, ± 10%
- Minimum Power Input: 12 V, 1.12 A
- Power Adapter: AC to DC, DC 12 V/3.0 A, 36 W (Optional)
- Typical: 11 W (with Intel Atom D510 at 1.66 GHz)
- Max.: 15 W (with Intel Atom D510 at 1.66 GHz)
- Construction: Aluminum housing
- Mounting: DIN-rail mounting, Desk/wall-mounting
- Dimensions (W x H x D): 264.5 mm x 69.2 mm x 137.25 mm (10.41″ x 2.72″ x 5.4″)
- Weight: 2 kg (4.4 lb)
- Operating Temperature:
- Storage Temperature: -40 ~ 85° C (-40 ~ 185°F)
- Relative Humidity: 95% @ 40° C (non-condensing)
- Vibration Loading During Operation:
- Shock During Operation: With CompactFlash disk: 50 G, IEC 60068-2-27, half sine, 11 ms duration
- EMC: CE/FCC Class A, CCC, BSMI, KC
- Safety Certifications: UL, CCC, BSMI, KC
ARK-3360L-N4A1E
ARK-3360L-D5A1E
Memory
Graphics
18-bit LVDS interface (Optional)
Ethernet
Audio
IO interface
Other
Expansion
Storage
Software Support
Power Requirement
Power Consumption
Mechanical
nvironment
With extended temperature peripherals: -20 ~ 60° C (-4 ~ 140°F); -40 ~ 70° C (-40 ~ 158° F) for ARK-3360LZ-
N4A1E
With 2.5-inch hard disk 0 to 45° C (32 ~ 112° F), with 0.7m/s air flow
With CompactFlash disk: 5 Grms, IEC 60068-2-64, random, 5 ~ 500 Hz, 1 Oct./min, 1 hr/axis.
With 2.5-inch hard disk: 1 Grms, IEC 60068-2-64, random, 5 ~ 500 Hz, 1 Oct./min, 1 hr/axis.
With hard disk: 20 G, IEC 60068-2-27, half sine, 11 ms duration
